The S-UM6522E from ABLIC U.S.A. Inc. is a versatile analog switch designed for high-speed applications. Its wide voltage range, from 0V to ±100V, allows it to handle signals with significant overshoot, up to ±150V. This makes it suitable for a broad range of analog signal processing tasks. Further, its frequency response extends from 10kHz to 85MHz, enabling use in high-frequency systems. The 2A peak current per channel and low on-resistance (8Ω) ensure efficient signal transmission.
Key features of the S-UM6522E include its high-speed 32-bit shift registers, which contribute to fast switching times. The inclusion of a 40kΩ bleed resistor on the probe side and low on/off capacitance further enhance the device's performance. This combination of features, from handling high voltages to fast switching, positions the S-UM6522E as a robust and effective solution for a wide spectrum of analog signal switching requirements.Nantian Electronics, a trusted ABLIC U.S.A. Inc. distributor, has a substantial inventory of the S-UM6522E in stock. We offer comprehensive support, providing the S-UM6522E datasheet (PDF) and detailed pin diagrams for easy reference. For a competitive quote and to place your order, please don't hesitate to contact us.
We're ready to discuss your needs and provide our best pricing. Inquiry and orders are welcome!
