Introduction
The KSZ9031RNXCC-TR is a highly efficient Ethernet controller from the well-known manufacturer, Microchip Technology. It is designed for high-speed data communication and supports a maximum data rate of 1 Gbps.
Microchip Technology is the manufacturer of the KSZ9031RNXCC-TR, which is available in stock at Nantian. The reference price for KSZ9031RNXCC-TR can be found by referring to Microchip Technology or Nantian's listings. For detailed parameters and understanding its functionality, you can refer to the KSZ9031RNXCC-TR datasheet PDF and pin diagram description that are available for download.
The KSZ9031RNXCC-TR has a wide range of applications as outlined in DSP Datasheet PDF. To further understand how it works, you can find usage methods along with circuit diagrams within these resources. For comprehensive electronics tutorials on using this component, these documents should prove highly beneficial.
All relevant information including datasheets, pin diagrams, circuit diagrams and tutorials related to KSZ9031RNXCC-TR could be downloaded from Nantian's platform.
Key Features
Data Rate: The device supports an impressive maximum data rate of 1Gbps, enabling fast and efficient transmission of information across networks.
Ethernet Speeds: It offers multiple ethernet speeds including 10Mbps,100Mbps and up to 1000Mbps facilitating flexible network configurations based on speed requirements.
Ethernet Interface Type: The product uses RGMII (Reduced Gigabit Media Independent Interface) as its interface type which provides a high-speed connection between the MAC layer and PHY layer in networking devices.
Voltage Parameters: The controller operates within varying supply voltage ranges with minimum operating supply voltages at values like 1.14V, 1.71V etc., typical operating supply voltage at values such as 1.8V,2.5V etc.,and maximum operating supply voltages at points like 1.38v ,2.625v etc.These specifications offer flexibility for different system power requirements.
Operating Conditions and Packaging Details
The KSZ9031RNXCC-TR can function effectively within an extensive temperature range from zero degree Celsius to seventy degree Celsius making it suitable for operation under diverse environmental conditions.The device comes in 'Tape & Reel' packaging that allows safe transport & storage before installation onto devices.It's surface mount technology enhances assembly efficiency while reducing costs associated with manual insertion processes.
The package dimensions are quite compact with maximum package height at just 0.85 mm and width & length both measuring seven millimeters each.
Additional Features
The KSZ9031RNXCC-TR supports standard protocols like 10BASE-T,100BASE-TX,1000BASE-T along with IEEE 802.3 which makes it compatible with a wide range of networking devices.
It's important to note that the device does not support PHY Line Side Interface,JTAG or Integrated CDR features.
The device consumes a typical supply current of about 221 mA indicating its power-efficient nature.The power supply types supported are both Analog & Digital.
Changes in PCB
The PCB has undergone forty-eight changes ensuring it stays updated with latest technological advancements for optimal performance.
