Texas Instruments DRV5055A4EDBZRQ1

Manufacturer Part Number :	DRV5055A4EDBZRQ1
Manufacturer :	Texas Instruments
Description :	1 mA~6mA, - 40 C ~ +150,12.5 mV/mT HALL EFFECT SENSOR
Datasheet :	DRV5055A4EDBZRQ1.PDF
EDA / CAD Models :	DRV5055A4EDBZRQ1 by SnapEDA
Base Product Number :	DRV5055
Stock Condition :	In Stock 5965, New Original

Quantity:

RFQ Add to RFQ List

Delivery:

Payment:

Request for Quotation

*Contact Name:

*Company Name:

*Email:

Country :

* Quantity

Remark :

Please fill the form and we'll get back to you within 24 hours.

Quick RFQ

Texas Instruments DRV5055A4EDBZRQ1

In Stock: 5965 Qty:

RFQ Now Add to RFQ list

The Texas Instruments DRV5055A4EDBZRQ1 is a highly sensitive, ratiometric linear Hall Effect magnetic sensor designed for precise magnetic field measurement. This sensor, belonging to the DRV5055-Q1 series, operates with an operating supply voltage range of 3.3V to 5V, making it versatile for various applications. It boasts an operating supply current of 6 mA and can handle a maximum output current of 1 mA. Packaged in a compact SOT-23-3 case, it is ideal for surface-mount technology (SMD/SMT) applications, ensuring ease of integration into compact designs.

/Product-Files/2024/7/DRV5055A4EDBZRQ1 3.jpg

As a professional Texas Instruments distributor, Nantian Electronics has a large number of DRV5055A4EDBZRQ1 in stock. We also provide DRV5055A4EDBZRQ1 parameters, DRV5055A4EDBZRQ1 Datasheet PDF and pin diagram instructions for download.

Original DRV5055A4EDBZRQ1 in stock

Features:

Operating supply current: 6 mA
Maximum output current: 1 mA
Operating supply voltage: 3.3V to 5V
Output voltage: 5.3V
High sensitivity: 12.5 mV/mT
Operating temperature range: -40°C to +150°C
Compact SOT-23-3 package for SMD/SMT mounting
Moisture sensitivity: Yes
Qualified to AEC-Q100 standards

Applications:

Automotive systems
Industrial automation
Consumer electronics
Robotics
Magnetic field measurement

Product Attribute	Attribute Value
Manufacturer:	Texas Instruments
Product Category:	Board Mount Hall Effect / Magnetic Sensors
RoHS:	Details
Type:	Ratiometric Linear
Operating Supply Current:	6 mA
Maximum Output Current:	1 mA
Operating Point Min/Max:	+/- 169 mT, +/- 176 mT
Operating Supply Voltage:	3.3 V, 5 V
Minimum Operating Temperature:	- 40 C
Maximum Operating Temperature:	+ 150 C
Mounting Style:	SMD/SMT
Package / Case:	SOT-23-3
Series:	DRV5055-Q1
Qualification:	AEC-Q100
Packaging:	Reel
Packaging:	Cut Tape
Packaging:	MouseReel
Brand:	Texas Instruments
Moisture Sensitive:	Yes
Output Type:	Analog
Output Voltage:	5.3 V
Product Type:	Board Mount Hall Effect / Magnetic Sensors
Sensitivity:	12.5 mV/mT
Factory Pack Quantity:	3000
Subcategory:	Sensors
Supply Voltage - Max:	5.5 V
Supply Voltage - Min:	3 V
Termination Style:	SMD/SMT
