Name: MX23A26NF1
Brand: JAE Electronics Inc.
SKU: MX23A26NF1
Rating: 5.0 (1 reviews)

JAE Electronics Inc. MX23A26NF1

Manufacturer Part Number :	MX23A26NF1
Manufacturer :	JAE Electronics Inc.
Description :	CONN HEADER R/A 26POS 2.5MM
Package :	26POS
Datasheet :	MX23A26NF1.PDF
EDA / CAD Models :	MX23A26NF1 by SnapEDA
Base Product Number :	MX23
Stock Condition :	In Stock 10840, New Original

Delivery:

Payment:

The JAE Electronics Inc. MX23A26NF1 is a through-hole connector header. Its right-angle design makes it suitable for applications where space is limited or a specific routing angle is needed. This 26-position connector uses 0.098" (2.50mm) pitch spacing, allowing for a compact and efficient connection of multiple electronic components. This header is a reliable choice for various electronic assembly projects.

JAE Electronics Inc. MX23A26NF1 connector part

Nantian Electronics, a dedicated JAE Electronics Inc. distributor, maintains a substantial stock of MX23A26NF1 components. We provide the necessary specifications and details for this part.

JAE Electronics Inc. MX23A26NF1 original package label

Type	Description
Category	Connectors, Interconnects Rectangular - Board to Board Connectors - Headers, Male Pins
Mfr	JAE Electronics
Series	MX23A
Packaging	Bulk
Part Status	Active
Connector Type	Header
Contact Type	Male Pin
Pitch - Mating	0.098" (2.50mm)
Number of Positions	26
Number of Rows	2
Row Spacing - Mating	0.173" (4.40mm)
Number of Positions Loaded	All
Style	Board to Cable/Wire
Shrouding	Shrouded - 4 Wall
Mounting Type	Through Hole, Right Angle
Termination	Solder
Fastening Type	Latch Holder
Contact Length - Mating	-
Contact Length - Post	0.122" (3.10mm)
Overall Contact Length	-
Insulation Height	0.720" (18.30mm)
Contact Shape	Square
Contact Finish - Mating	Tin
Contact Finish Thickness - Mating	-
Contact Finish - Post	Tin
Contact Material	Brass
Insulation Material	Polybutylene Terephthalate (PBT), Glass Filled
Features	Board Guide
Operating Temperature	-40°C ~ 125°C
Ingress Protection	Waterproof
Material Flammability Rating	-
Insulation Color	Black
Current Rating (Amps)	3A
Voltage Rating	-
Mated Stacking Heights	-
Contact Finish Thickness - Post	-
Applications	Automotive
Base Product Number	MX23A26N
