The TLV431ALPRAG from onsemi is a precision adjustable shunt voltage reference IC designed for stable voltage regulation in a wide variety of electronic applications. With an adjustable output voltage range from 1.24 V to 16 V, it offers excellent versatility for use in power supplies, voltage monitoring, and control systems. This device provides a voltage reference tolerance of ±1% for the A series, ensuring reliable performance and consistent accuracy across operating conditions. Its low dynamic output impedance of 0.2 Ω and sharp turn-on characteristics make it ideal for circuits requiring fast response and precise voltage control, even at low operating currents.
Operating efficiently across a wide current range from 50 µA to 20 mA, the TLV431ALPRAG combines stability, low noise, and low power consumption in a compact TO-92 (TO-226) package. It is also available in other miniature package options for space-constrained designs. The device meets automotive-grade quality standards, being AEC-Q100 qualified and PPAP capable, making it suitable for both consumer and automotive applications that demand long-term reliability.
As a trusted onsemi distributor, Nantian Electronics maintains a substantial inventory of the TLV431ALPRAG and provides complete technical resources, including datasheets and pin diagram documentation, to assist engineers and purchasers in their design and sourcing needs. Customers are encouraged to contact us for competitive pricing and dedicated support.
