Omron XF3M(1)-1015-1B

Manufacturer Part Number :	XF3M(1)-1015-1B
Manufacturer :	Omron
Description :	CONN FFC 10POS 1MM R/A
Package :	10POS
Datasheet :	XF3M(1)-1015-1B.PDF
EDA / CAD Models :	XF3M(1)-1015-1B by SnapEDA
Base Product Number :	XF3
Stock Condition :	In Stock 28570, New Original

Quantity:

RFQ Add to RFQ List

Delivery:

Payment:

Request for Quotation

*Contact Name:

*Company Name:

*Email:

Country :

* Quantity

Remark :

Please fill the form and we'll get back to you within 24 hours.

Quick RFQ

Omron XF3M(1)-1015-1B

In Stock: 28570 Qty:

RFQ Now Add to RFQ list

The XF3M(1)-1015-1B from Omron is a compact and reliable FFC/FPC connector designed for high-density signal connections in modern electronic devices. It features 10 positions with a 1.0mm pitch and a right-angle, surface-mount structure, allowing efficient use of PCB space while ensuring secure and stable connections. With top and bottom contact design options and compatibility with 0.3mm thick FPC/FFC cables, it offers flexibility for various design requirements.

Omron XF3M(1)-1015-1B connector chip

This connector is widely used in consumer electronics, display modules, and compact embedded systems where space-saving and dependable connectivity are essential. Its robust construction and available plating options help maintain good electrical performance and durability over time.

Omron XF3M(1)-1015-1B original reel label

Nantian Electronics, as a professional Omron distributor, keeps XF3M(1)-1015-1B in stock and provides datasheets and technical support, welcoming inquiries for pricing and orders.

Type	Description
Category	Connectors, Interconnects FFC, FPC (Flat Flexible) Connectors - Accessories
Manufacturer	Omron Electronics
Series	XF3M
Packaging	Tape & Reel (TR)
Part Status	Active
Flat Flex Type	FFC, Discrete Wire
Mounting Type	Surface Mount, Right Angle
Connector/Contact Type	Contacts, Top and Bottom
Number of Positions	10
Pitch	0.039" (1.00mm)
Termination	Solder
FFC, FCB Thickness	0.30mm
Height Above Board	0.079" (2.00mm)
Locking Feature	Rotary Lock, Backlock
Cable End Type	Tapered
Contact Material	Copper Alloy
Contact Finish	Gold
Housing Material	Liquid Crystal Polymer (LCP), Halogen Free
Actuator Material	Liquid Crystal Polymer (LCP), Halogen Free
Features	Solder Retention
Voltage Rating	50V
Operating Temperature	-30°C ~ 85°C
Material Flammability Rating	UL94 V-0
Current Rating (Amps)	0.5A
Contact Finish Thickness	Flash
Housing Color	Natural
Actuator Color	Black
Mating Cycles	20
Base Product Number	XF3M

What are its key features?

10-position FFC/FPC connector, 1.0mm pitch, right-angle surface-mount design, dual-side contacts, and support for 0.3mm cable thickness.

What is it used for?

Used for flexible cable connections in consumer electronics, display modules, and compact embedded devices.

Are there alternative parts?

Yes, alternatives include similar FFC/FPC connectors from Omron, as well as compatible parts from Hirose, TE Connectivity, and Molex with similar pitch and configuration.
