Product Overview:
NXP's MPX5700ASX is a state-of-the-art integrated silicon pressure sensor designed for a wide range of applications but particularly suited for those requiring a robust solution to measure absolute pressure. Its ability to withstand harsh conditions while delivering accurate readings makes it an excellent choice across different industries such as automotive, industrial controls, and consumer electronics.
NXP MPX5700ASX physical picture-six gold pins
Key Features:
Wide Measurement Range: Capable of measuring pressures ranging from 15 kPa to 700 kPa.
Temperature Compensated: Offers temperature-compensated outputs which ensure accuracy over its operating temperature range.
Durable Construction: The device features monolithic silicon dioxide construction that provides high reliability and performance stability even under adverse conditions.
Versatile Output Signal: Provides an analog output signal that can be easily interfaced with common electronic components or microcontrollers.
Technical Specifications:
Supply Voltage: 4.85 V to 5.35 V
Operating Temperature Range: -40°C to +125°C
Full Scale Span (Typical): ~4.90V
Ideal Applications:
This versatile sensor can be effectively used in scenarios including:
Automotive systems such as engine control units (ECU), transmission controls, suspension systems where monitoring system or environmental pressures are crucial.
Industrial equipment like pneumatic control systems or fluid level indicators requiring consistent precision at varying temperatures/pressures.
Consumer appliances where sensing elements contribute towards enhancing safety/performance parameters.
Competitive Advantages:
Compared with similar products on the market:
The MPX5700ASX offers wider measurement ranges enabling greater versatility across multiple application domains.
It ensures superior performance through built-in temperature compensation maintaining accuracy despite fluctuating ambient conditions.
Backed by NXP’s reputation for quality and support, customers benefit from comprehensive documentation easing integration efforts into diverse designs.
MPX5700ASX Same series model:
The NXP Semiconductors' MPX5700ASX is part of the MPX5700 series of integrated silicon pressure sensors. These sensors are designed for a wide range of applications, particularly those employing microcontrollers or microprocessors with A/D inputs.
Other models in this series include:
MPX5700AP: This model has an absolute pressure range from 15 to 700 kPa. It's unported and comes in a through-hole package.
MPX5700GP: Like the AP variant, it also covers an absolute pressure range from 15 to 700 kPa but is ported and comes in a through-hole package.
MPX5700DP: Another similar sensor with the same pressure range (15-700kPa), but this one features dual ports and also uses a through-hole packaging style.
All these variants have very similar specifications as they belong to the same series:
They operate over a temperature range of -40°C to +125°C
They come calibrated from the factory
Their accuracy ranges within ±2% Maximum Error over 0° C to +85° C (Pressure)
Please note that while these devices share many similarities due to being part of the same product line, there may be minor differences between them related mainly to their form factor (e.g., single port vs dual port) or method of connection (surface mount vs through hole).
To choose among them, consider your specific application requirements including available space on your PCB, how you plan on connecting your sensor physically and electrically, etc.
For more detailed comparison or if you're looking at other parameters not mentioned here, I'd recommend checking out their respective datasheets which will provide comprehensive details about each device's performance characteristics and recommended usage scenarios(MPX5700GP Datasheet, MPX5700DP DataSheet).
