The PESD5Z2.5,115 from Nexperia is a high-performance transient voltage suppression (TVS) diode designed to provide reliable electrostatic discharge (ESD) and surge protection for sensitive electronic circuits. Housed in an ultra-small SOD-523 surface-mount package, this device offers excellent protection for one signal line without occupying significant board space, making it ideal for compact consumer and industrial electronics. It features a maximum clamping voltage of 15 V and a peak pulse current of 20 A (8/20 μs waveform), providing strong defense against voltage spikes caused by electrostatic discharge or electrical transients. The diode’s low capacitance minimizes signal distortion in high-speed data lines, ensuring signal integrity in applications such as USB, HDMI, sensor interfaces, and communication ports.
Engineered for high reliability and durability, the PESD5Z2.5,115 supports ESD protection levels up to ±30 kV according to the IEC 61000-4-2 standard, along with surge immunity compliant with IEC 61000-4-5. Its low leakage current of just 0.5 μA helps maintain overall system power efficiency, while the low clamping voltage of 8 V ensures optimal protection of downstream components. This combination of strong transient suppression, small footprint, and robust electrical performance makes it an excellent choice for automotive, industrial, and portable device designs where long-term reliability is essential. As a professional Nexperia distributor, Nantian Electronics maintains a substantial inventory of the PESD5Z2.5,115 and provides complete technical support, including datasheets, electrical characteristics, and pin configuration details. Customers can contact us for competitive pricing, fast delivery, and professional assistance to ensure seamless integration of the PESD5Z2.5,115 into their protection circuit designs.
