Maxim Integrated MAX16813ATP/V+T

The Maxim Integrated MAX16813ATP/V+T is a versatile and high-performance 4-channel linear LED driver designed to independently power multiple LED strings with precision and efficiency. Featuring internal MOSFETs, it supports adjustable full-scale LED currents ranging from 20mA to 150mA, making it suitable for diverse applications. This device enables up to four LED strings to be driven simultaneously and provides exceptional PWM dimming capabilities, achieving a 10,000:1 ratio at 200Hz for finely tuned brightness control. Its flexible current-mode architecture helps minimize interference while supporting configurations such as boost or SEPIC current-mode DC-DC controllers, with programmable switching frequencies from 200kHz to 2MHz and external synchronization options.

Designed with advanced protection features, the MAX16813ATP/V+T ensures system reliability and fault detection with undervoltage protection, open-LED and LED-short detection, as well as overtemperature safeguards. Adaptive output-voltage optimization reduces power dissipation, and the device consumes less than 2μA in shutdown mode for energy efficiency. Ideal applications include automotive LED backlighting for displays, RCL, DRL, and fog lights, as well as LCD TV displays, architectural lighting, and ambient illumination. Maxim Integrated has crafted this LED driver for precision and reliability in demanding environments, and Nantian Electronics offers a large stock with full support for technical specifications and competitive pricing. Contact us to learn more or place an order!
