Q1: What are the main features of the 12401832E402A?
The 12401832E402A is a USB Type-C receptacle connector designed for USB 3.2 Gen 2 high-speed applications. It supports data transfer rates up to 20 Gb/s and provides reliable high-power charging capability. The connector features a 24-position design with right-angle surface mount and through-hole attachment for strong PCB retention and stable electrical performance. Its reversible plug orientation allows easy insertion from either side, improving user convenience. The durable mid-plate tongue structure enhances mechanical strength and supports long operational life in repeated connection cycles.
Q2: What applications is it commonly used for?
This connector is widely used in laptops, tablets, smartphones, docking stations, industrial equipment, communication systems, gaming devices, and IoT products. It is suitable for applications requiring high-speed data transfer, USB power delivery, compact design, and reliable connectivity in modern electronic systems.
Q3: Are there alternative manufacturers or part numbers?
Yes. Similar USB Type-C connectors are available from manufacturers such as TE Connectivity, Molex, Hirose Electric, JAE, and GCT. Comparable products may include USB 3.2 Gen 2 Type-C receptacles with similar mounting styles and performance specifications. Before selecting an alternative, designers should compare mechanical dimensions, pin layout, current rating, and durability specifications to ensure compatibility.
Q4: Is technical support available for this part?
Yes. Amphenol ICC provides technical documentation including datasheets, product drawings, and application information for the 12401832E402A. In addition, suppliers such as Nantian Electronics offer technical assistance, datasheet downloads, and support for product selection and integration into customer designs.
