PANJIT SVM1045VA_R2_00001

Name: SVM1045VA_R2_00001
Brand: PANJIT
SKU: SVM1045VA_R2_00001
Rating: 5.0 (1 reviews)

Manufacturer Part Number :	SVM1045VA_R2_00001
Manufacturer :	PANJIT
Description :	DIODE SCHOTTKY 45V 10A TO277A
Datasheet :	SVM1045VA_R2_00001.PDF
EDA / CAD Models :	SVM1045VA_R2_00001 by SnapEDA
Base Product Number :	SVM1045
Stock Condition :	In Stock 60000, New Original

Quantity:

RFQ Add to RFQ List

Delivery:

Payment:

Request for Quotation

*Contact Name:

*Company Name:

*Email:

Country :

* Quantity

Remark :

Please fill the form and we'll get back to you within 24 hours.

Quick RFQ

PANJIT SVM1045VA_R2_00001

In Stock: 60000 Qty:

RFQ Now Add to RFQ list

The PANJIT SVM1045VA_R2_00001 is a high-efficiency Schottky rectifier designed for applications demanding excellent performance and energy savings. With its ultra-low forward voltage drop, this rectifier minimizes power loss, making it ideal for high-efficiency operations in modern electronics. The device's low thermal resistance ensures efficient heat dissipation, contributing to stable and reliable performance even under demanding conditions. Its compatibility with automated placement processes further enhances its utility in streamlined manufacturing environments.

PANJIT SVM1045VA_R2_00001 electronic chip

Compliant with the EU RoHS 2011/65/EU directive, the SVM1045VA_R2_00001 is a lead-free device designed with environmental sustainability in mind. Its robust features and efficient design make it a versatile solution for a wide range of applications, from power supplies to electronic circuits requiring reliable rectification. Compact and reliable, this Schottky rectifier is a dependable choice for designers seeking high performance with minimal energy loss.

PANJIT SVM1045VA_R2_00001 original reel label

Type	Description
Category	Discrete Semiconductor Products Diodes - Rectifiers - Single
Mfr	Panjit International Inc.
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
Technology	Schottky
Voltage - DC Reverse (Vr) (Max)	45 V
Current - Average Rectified (Io)	10A
Voltage - Forward (Vf) (Max) @ If	470 mV @ 10 A
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr	250 µA @ 45 V
Capacitance @ Vr, F	-
Mounting Type	Surface Mount
Package / Case	TO-277, 3-PowerDFN
Supplier Device Package	TO-277A
Operating Temperature - Junction	-55°C ~ 150°C
Base Product Number	SVM1045
