The FAN7389MX1, manufactured by ON Semiconductor, is a high-performance gate driver designed for IGBT and MOSFET applications. It is a half-bridge type gate driver with three drivers and three outputs, providing ample interfacing options for various applications. The device can output a current of up to 650 mA, making it suitable for driving a wide range of power transistors. It operates within a supply voltage range of 10V to 20V, providing flexibility in diverse electronic systems.
Designed for surface mount applications, the FAN7389MX1 comes in an SOIC-28 package. It features a rise time of 50 ns and a fall time of 30 ns, ensuring fast and efficient switching. Furthermore, it can operate within a temperature range of -40°C to +125°C, making it robust in various environmental conditions. The FAN7389MX1 also comes with several integrated features, including an advanced input filter, shoot-through prevention logic, soft turn-off function, common-mode dv/dt noise canceling circuit, and under-voltage lockout functions for all channels.
Applications
What is the output current capability of the FAN7389MX1?
The FAN7389MX1 can provide an output current of up to 650 mA.
What is the operating temperature range of the FAN7389MX1?
The FAN7389MX1 can operate within a temperature range of -40°C to +125°C.
