Nichicon UHW1K221MPD

Name: UHW1K221MPD
Brand: Nichicon
SKU: UHW1K221MPD
Rating: 5.0 (1 reviews)

Manufacturer Part Number :	UHW1K221MPD
Manufacturer :	Nichicon
Description :	80V 221UF 20% HIGH RELIA-LEADED
Datasheet :	UHW1K221MPD.PDF
EDA / CAD Models :	UHW1K221MPD by SnapEDA
Base Product Number :	UHW1
Stock Condition :	In Stock 79590, New Original

Quantity:

RFQ Add to RFQ List

Delivery:

Payment:

Request for Quotation

*Contact Name:

*Company Name:

*Email:

Country :

* Quantity

Remark :

Please fill the form and we'll get back to you within 24 hours.

Quick RFQ

Nichicon UHW1K221MPD

In Stock: 79590 Qty:

RFQ Now Add to RFQ list

The Nichicon UHW1K221MPD is a high-performance aluminum electrolytic capacitor designed for applications requiring lower impedance at high frequencies. Its compact case size and ability to handle high ripple currents make it ideal for modern electronics, where space efficiency and reliable performance are critical. This capacitor delivers stable operation and excellent durability, meeting the demands of a wide range of power supply and filtering applications.

Nichicon UHW1K221MPD electronic chip

Fully compliant with the RoHS directive (2011/65/EU and (EU)2015/863), the UHW1K221MPD aligns with environmental standards, ensuring safe and sustainable use. Its combination of advanced features and a smaller footprint provides versatility and efficiency for various designs.

Nichicon UHW1K221MPD package label

Nantian Electronics maintains a large stock of the UHW1K221MPD, along with detailed datasheets and pin diagrams to support successful integration into your projects. Contact us for competitive pricing and reliable delivery options.

Type	Description
Category	Capacitors Aluminum Electrolytic Capacitors
Mfr	Nichicon
Series	UHW
Packaging	Bulk
Part Status	Active
Capacitance	220 µF
Tolerance	±20%
Voltage - Rated	80 V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	10000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	810 mA @ 120 Hz
Ripple Current @ High Frequency	1.62 A @ 100 kHz
Impedance	72 mOhms
Lead Spacing	0.197" (5.00mm)
Size / Dimension	0.394" Dia (10.00mm)
Height - Seated (Max)	1.043" (26.50mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can
