What is the BAT54C,215?
The BAT54C,215 is a dual Schottky diode array from Nexperia configured in a common-cathode arrangement. It is designed for fast switching, low-voltage applications, and efficient signal handling in compact electronic systems.
What are the key features of this diode?
Important features include a low forward voltage drop for improved energy efficiency, low capacitance for high-speed signal performance, a 30 V reverse voltage rating, and a 200 mA continuous forward current capability. It is packaged in a small TO-236-3 (SOT-23-3/SC-59) surface-mount housing suitable for dense PCB layouts.
What applications typically use the BAT54C,215?
This device is widely used in portable electronics, communication modules, logic-level circuits, and general-purpose switching. It is also suitable for polarity protection, clamping circuits, and high-speed signal routing due to its fast response and stable electrical characteristics.
Why is the low forward voltage important?
A low forward voltage reduces power loss and heat dissipation, which is especially valuable in low-voltage and battery-powered systems where efficiency is critical.
What advantage does low capacitance provide?
Low capacitance helps maintain clean signal transitions at high frequencies, making the device ideal for fast-switching applications and high-speed digital circuits.
What does “common cathode configuration” mean?
In a common-cathode configuration, the two diode anodes are independent, but they share a single cathode connection. This arrangement is useful for signal steering, protection networks, and circuits that require symmetrical switching behavior.
Where can technical documents and pricing information be obtained?
Nantian Electronics provides datasheets, detailed parameters, pin-diagram instructions, and maintains stock of the BAT54C,215. Customers can contact them directly for quotations and ordering support.
