The 74HC00BQ,115 from Nexperia is a high-speed CMOS logic IC that integrates four independent NAND gates within a compact 14-pin DHVQFN package measuring just 2.5 mm by 3 mm. Designed for efficiency and reliability, it operates across a wide supply voltage range of 2.0 V to 6.0 V, offering excellent flexibility for use in both low- and high-voltage digital systems. The device features low power dissipation and high noise immunity, ensuring stable operation even in electrically noisy environments. It is fully compliant with JEDEC standards JESD8C and JESD7A, which define robust performance from 2.0 V to 6.0 V operating ranges. Each gate delivers reliable switching characteristics ideal for timing, control, and logic functions in a broad range of electronic applications.
Engineered with strong protection and durability, the 74HC00BQ,115 provides superior ESD protection withstanding voltages over 2000 V (HBM) and 1000 V (CDM), while its latch-up immunity exceeds 100 mA as per JESD 78 Class II Level B. These characteristics make it suitable for use in automotive, industrial, and consumer electronics that require high endurance and safety. The component’s wide operating temperature range, from -40 °C to +125 °C, ensures dependable performance under harsh conditions.
As an authorized Nexperia distributor, Nantian Electronics maintains a comprehensive inventory of the 74HC00BQ,115, along with datasheets and pin configuration resources for download. Customers are welcome to contact us for technical assistance, quotations, and orders at competitive prices.
