Name: 20021221-00010C4LF
Brand: FCI
SKU: 20021221-00010C4LF
Rating: 5.0 (1 reviews)

FCI 20021221-00010C4LF

Manufacturer Part Number :	20021221-00010C4LF
Manufacturer :	FCI
Description :	CONN HEADER SMD 10POS 1.27MM
Datasheet :	20021221-00010C4LF.PDF
EDA / CAD Models :	20021221-00010C4LF by SnapEDA
Stock Condition :	In Stock 10000, New Original

Delivery:

Payment:

The FCI 20021221-00010C4LF connector is a versatile, high-quality component designed for reliable connections in various electronic devices. Its fine pitch of 1.27mm allows for compact designs, and the connector's availability in positions ranging from 4 to 100 provides flexibility for diverse applications. The shrouded housing ensures protection against environmental factors, while the choice of three plating options (gold, gold flash) caters to different application needs and cost considerations. The availability of both top and bottom entry versions further enhances design possibilities.

FCI 20021221-00010C4LF connector part

Nantian Electronics, a trusted FCI distributor, stocks the FCI 20021221-00010C4LF connector. Our inventory allows for rapid delivery and ensures access to this crucial component for your projects, whether surface mount or through hole applications are required.

FCI 20021221-00010C4LF original reel label

Type	Description
Category	Connectors, Interconnects Rectangular - Connectors Headers, Male Pins
Mfr	Amphenol ICC (FCI)
Series	Minitek127® 1.27mm
Packaging	Tape & Reel (TR)
Part Status	Active
Connector Type	Header
Contact Type	Male Pin
Pitch - Mating	0.050" (1.27mm)
Number of Positions	10
Number of Rows	2
Row Spacing - Mating	0.050" (1.27mm)
Number of Positions Loaded	All
Style	Board to Board
Shrouding	Shrouded - 4 Wall
Mounting Type	Surface Mount
Termination	Solder
Fastening Type	Push-Pull
Contact Length - Mating	0.120" (3.05mm)
Contact Length - Post	-
Overall Contact Length	-
Insulation Height	0.220" (5.60mm)
Contact Shape	Square
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	10.0µin (0.25µm)
Contact Finish - Post	Tin
Contact Material	Copper Alloy
Insulation Material	Thermoplastic
Features	Pick and Place
Operating Temperature	-55°C ~ 125°C
Ingress Protection	-
Material Flammability Rating	UL94 V-0
Insulation Color	Black
Current Rating (Amps)	1A per Contact
Voltage Rating	125VAC
Mated Stacking Heights	-
Contact Finish Thickness - Post	50.0µin (1.27µm)
Applications	-
Base Product Number	20021221
