Diodes Incorporated PI3C3125LEX

Manufacturer Part Number :	PI3C3125LEX
Manufacturer :	Diodes Incorporated
Description :	IC 4-BIT BUS SW 2-PORT
Package :	14-TSSOP
Datasheet :	PI3C3125LEX.PDF
EDA / CAD Models :	PI3C3125LEX by SnapEDA
Base Product Number :	PI3
Stock Condition :	In Stock 8704, New Original

Quantity:

RFQ Add to RFQ List

Delivery:

Payment:

Request for Quotation

*Contact Name:

*Company Name:

*Email:

Country :

* Quantity

Remark :

Please fill the form and we'll get back to you within 24 hours.

Quick RFQ

Diodes Incorporated PI3C3125LEX

In Stock: 8704 Qty:

RFQ Now Add to RFQ list

The PI3C3125LEX from Diodes Incorporated is a high-performance bus switch designed to provide fast and efficient signal routing in digital systems. With near-zero propagation delay and low on-resistance of approximately 5 ohms, it enables signals to pass through with minimal distortion and loss. Its high bandwidth of over 400 MHz makes it suitable for high-speed data applications, while supporting rail-to-rail switching as well as operation at 2.5V or 3.3V logic levels.

Diodes Incorporated PI3C3125LEX semiconductor IC

This device is built for flexibility and reliability, featuring 5V I/O tolerance and the ability to support hot insertion, which helps protect systems during live connection or removal. Operating at a low supply voltage of 2.5V, it is ideal for modern low-power designs. The PI3C3125LEX is commonly used in applications such as signal multiplexing, bus isolation, and data path switching in communication and computing systems.

Diodes Incorporated PI3C3125LEX original reel label

Nantian Electronics offers strong inventory availability of this component, along with complete technical documentation and competitive pricing to support customer requirements.

Package	14-TSSOP (0.173", 4.40mm Width)
RoHS	RoHS
Type	Bus Switch
Circuit	1 x 1:1
Mounting Type	Surface Mount
Package / Case	14-TSSOP (0.173", 4.40mm Width)
Product Status	Active
Voltage - Supply	2.3V ~ 3.6V
Independent Circuits	4
Operating Temperature	-40°C ~ 85°C
Voltage Supply Source	Single Supply
Supplier Device Package	14-TSSOP
Current - Output High, Low	-

What is the PI3C3125LEX used for?

The PI3C3125LEX is a bus switch used to connect or isolate digital signals in high-speed systems. It is commonly used in data routing, signal multiplexing, and bus switching in communication equipment, computers, and embedded systems.

What are its key features?

It offers near-zero propagation delay, low on-resistance (~5Ω), and high bandwidth (>400 MHz) for fast and clean signal transmission. It supports 2.5V/3.3V operation, is 5V I/O tolerant, and allows hot insertion, improving system flexibility and reliability.

Does it have alternative parts?

Yes. Alternatives include similar bus switches from Diodes Incorporated or other manufacturers like Texas Instruments and NXP. When selecting a replacement, match parameters such as channel configuration, on-resistance, voltage range, bandwidth, and pin compatibility.
