The CYPD5225-96BZXIT part of the EZ-PD™ CCG5 series manufactured by Infineon Technologies, is a versatile USB controller designed to meet the demanding requirements of USB Power Delivery (USB-PD) 3.0 applications. It features dual integrated USB-PD Type-C ports, supporting both upstream-facing (UFP) and downstream-facing (DFP) roles with integrated role swapping capabilities for seamless power and data transfer. This controller integrates essential features like dead battery termination for power source/sink applications, VCONN FETs for EMCA cable power, and a high-voltage LDO operational up to 21.5V, ensuring robust performance across varied power requirements.
Equipped with a 48-MHz Arm Cortex-M0 CPU, 128KB Flash memory, and 12KB SRAM, the CYPD5225-96BZXIT delivers efficient processing and ample storage for complex USB-PD protocol handling. It supports multiple interfaces including I2C, SPI, and UART, alongside runtime configurable serial communication blocks for versatile connectivity. With compliance to USB 3.0 standards and a wide operating temperature range of -40°C to 85°C, this device is well-suited for diverse industrial, consumer electronics, and automotive applications requiring reliable USB connectivity and power management.
As a professional Cypress(Infineon) distributor, Nantian Electronics has a large number of CYPD5225-96BZXIT in stock. We also provide CYPD5225-96BZXIT parameters, CYPD5225-96BZXIT Datasheet PDF and pin diagram instructions for download.
Applications
Features
Integrated USB Power Delivery (USB-PD) 3.0 support
Two integrated USB-PD Type-C ports
Integrated UFP[1]
(RD) and current sources for DFP[2]
(RP) on
both Type-C ports
Integrated dead battery termination for DRP (Power
Source/Sink) applications
Integrated VCONN FETs to power EMCA cables
Integrated fast role swap and extended data messaging
Integrated high-voltage LDO, operational up to 21.5 V
Integrated 2x USB Analog Mux
48-MHz Arm Cortex-M0 CPU
128-KB Flash
12-KB SRAM
Up to two integrated timers and counters to meet response
times required by the USB-PD protocol
Four run-time serial communication blocks (SCBs) with
reconfigurable I2C, SPI, or UART functionality
