Avago Technologies (Broadcom) ABA-31563-TR1G

The ABA-31563-TR1G from Avago Technologies (now part of Broadcom) is a high-performance RF amplifier integrated circuit (IC).  Designed for a wide range of applications, this chip excels in amplifying radio frequency signals across the spectrum from 0Hz to 3.5GHz.  Its compact SOT-363 and SC70 packages make it ideal for space-constrained designs, while its strong performance characteristics ensure efficient signal processing.Key features include a substantial 21.5dB gain, excellent input/output matching indicated by a VSWR less than 2.0 across the entire operating range.  This translates to superior signal quality and minimal signal loss.  The high output power, as seen in the 2.2dBm output P1dB and 13.1dBm output IP3 figures, and the low noise figure of 3.8 dB, make this IC well-suited for applications requiring robust amplification without significant noise interference.  These characteristics make it an attractive option for various wireless communications systems.

Nantian Electronics, a professional Avago Technologies (Broadcom) distributor, has a substantial inventory of the ABA-31563-TR1G RF amplifier IC.  We offer immediate access to this component, along with comprehensive technical resources including the full datasheet (PDF) and detailed pin diagrams to facilitate your design integration.  Contact us today for a competitive quote.

Don't hesitate to reach out for any inquiries or to place an order.  We are committed to providing you with the best possible pricing and service.
