Texas Instruments MF10CCWMX/NOPB

The MF10CCWMX from Texas Instruments is a versatile universal switched-capacitor filter IC designed to simplify the implementation of precision analog filters. It integrates two matched second-order filter sections that can be configured to form low-pass, high-pass, band-pass, notch, or all-pass responses, enabling designers to realize up to a fourth-order filter within a single device. The center or cutoff frequency is directly set by an external clock, providing excellent accuracy and stability, with a clock-to-frequency ratio accuracy of about ±0.6%. This clock-controlled approach minimizes sensitivity to external component tolerances and allows easy adjustment of filter characteristics without redesigning the analog circuitry.

With operation supporting filter frequencies up to 200 kHz and practical signal bandwidths up to around 30 kHz, the MF10CCWMX is well suited for signal conditioning in audio processing, instrumentation, communications, and industrial control systems. It offers separate outputs for different filter responses, giving designers flexibility to select or combine outputs as needed. Available in wide-body SOIC and PDIP packages, the device is easy to integrate into both prototype and production designs. As a professional Texas Instruments supplier and distributor, Nantian Electronics maintains stock of MF10CCWMX and provides full documentation, including datasheets and pin diagrams, to support efficient design and procurement.
