What are the key features of the LMZ13610TZE/NOPB?
LMZ13610TZE/NOPB is a non-isolated DC-DC step-down (buck) power module that integrates the controller, power switches, inductor, and other components into a single compact package. It accepts a wide input voltage range from 6 V to 36 V and delivers a configurable output between 0.8 V and 6 V with up to 10 A of continuous current, making it suitable for high-current point-of-load power conversion. The module offers high efficiency, reduced external component count, and simplified design work compared with discrete power converters. Built-in protections help guard against over-current, over-temperature, and under-voltage conditions for improved system reliability.
What is it used for?
This power module is typically used to provide regulated low-voltage supply rails for digital and analog circuits in systems such as industrial controllers, telecom and networking equipment, embedded processors, FPGAs, and other electronics requiring robust intermediate power regulation. Its high current capacity and compact footprint make it ideal for designs where board space is limited but performance and efficiency are critical.
Does it have alternative parts?
Yes. Similar integrated PoL power modules and buck regulators are available from Texas Instruments (e.g., LMZ23610, LMZ21700) and other manufacturers such as Murata, RECOM, and TDK (i.e., isolated DC-DC modules with similar voltage/current ratings). When selecting an alternative, ensure the replacement supports the required input/output voltage range, output current, efficiency, protections, and package size for your application.
