Texas Instruments ISO7220CDR

Manufacturer Part Number :	ISO7220CDR
Manufacturer :	Texas Instruments
Description :	DGTL ISOLTR 2.5KV 2CH GP 8-SOIC
Datasheet :	ISO7220CDR.PDF
EDA / CAD Models :	ISO7220CDR by SnapEDA
Base Product Number :	ISO7220
Stock Condition :	In Stock 56800, New Original

Delivery:

Payment:

Request for Quotation

*Contact Name:

*Company Name:

*Email:

Country :

* Quantity

Remark :

Please fill the form and we'll get back to you within 24 hours.

Quick RFQ

Pricing

*All prices are in USD

Qty	Unit Price	Ext Price
1	$0.9230	$0.9230
50	$0.8307	$41.5350
100	$0.7476	$74.7600
500	$0.6729	$336.4500
1000	$0.6056	$605.6000

In Stock 56800 PCS

Subtotal : $0.000

Add to RFQ List Buy Now

*Products eligible for online ordering ship within 1-2 business days,please contact us for exact shipping times.

Texas Instruments ISO7220CDR

In Stock: 56800 Qty:

Unit Price: $

Ext Price: $

Add to Cart Buy Now RFQ Now Add to RFQ list

The ISO7220CDR from Texas Instruments is a high-performance general-purpose digital isolator designed to ensure reliable signal transmission across isolation barriers. Featuring two independent channels with a 2500Vrms isolation rating, it supports data rates up to 25Mbps and offers excellent noise immunity with a 25kV/µs common-mode transient immunity (CMTI). Built to operate from 2.8V to 5V supplies, this device minimizes signal distortion and jitter, ensuring accurate data communication even in electrically noisy environments. It is housed in an 8-SOIC package, making it suitable for compact, high-reliability circuit designs used in industrial and communication systems.

Texas Instruments ISO7220CDR electronic chip

As a professional Texas Instruments distributor, Nantian Electronics has a large stock of the ISO7220CDR electronic component. We also provide ISO7220CDR parameters, ISO7220CDR Datasheet (PDF), and pin diagram instructions for download. If you are interested in purchasing this part, please contact us. We will offer you the best price available. Welcome to send your inquiry and place your order!

Texas Instruments ISO7220CDR original package label

Type	Description
Category	Isolators Digital Isolators
Mfr	Texas Instruments
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
Technology	Capacitive Coupling
Type	General Purpose
Isolated Power	No
Number of Channels	2
Inputs - Side 1/Side 2	2/0
Channel Type	Unidirectional
Voltage - Isolation	2500Vrms
Common Mode Transient Immunity (Min)	25kV/µs
Data Rate	25Mbps
Propagation Delay tpLH / tpHL (Max)	42ns, 42ns
Pulse Width Distortion (Max)	2ns
Rise / Fall Time (Typ)	1ns, 1ns
Voltage - Supply	2.8V ~ 5.5V
Operating Temperature	-40°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package	8-SOIC
Base Product Number	ISO7220
