Name: 53047-1210
Brand: Molex
SKU: 53047-1210
Price: 0.1932 USD
Availability: InStock
Rating: 5.0 (3 reviews)

Molex 53047-1210

Manufacturer Part Number :	53047-1210
Manufacturer :	Molex
Description :	CONN HEADER VERT 12POS 1.25MM
Datasheet :	53047-1210.PDF
EDA / CAD Models :	53047-1210 by SnapEDA
Stock Condition :	In Stock 12000, New Original

Delivery:

Payment:

Qty

Unit Price

Ext Price

$0.1932

$0.1739

$8.6950

100

$0.1565

$15.6500

500

$0.1408

$70.4000

1000

$0.1268

$126.8000

The Molex 53047-1210 is a high-quality PicoBlade PCB header designed for compact and reliable connections in electronic systems. Featuring a 1.25mm pitch, this single-row, vertical through-hole header is equipped with 12 circuits and a friction lock mechanism for secure mating. Its tin plating ensures excellent conductivity and durability, while the 2.30mm PC tail length provides optimal fit and alignment during assembly. This component is ideal for applications that require space-saving designs without compromising performance.

Molex 53047-1210 connector part

Engineered for precision and reliability, the Molex 53047-1210 is commonly used in consumer electronics, industrial systems, and automotive applications. Nantian Electronics stocks a wide range of this product and offers detailed datasheets and pin diagram instructions for easy integration. Customers can inquire about availability and pricing to ensure seamless implementation in their projects.

Molex 53047-1210 original package label

Type	Description
Category	Connectors, Interconnects Rectangular Board to Board Connectors - Headers, Male Pins
Mfr	Molex
Series	PicoBlade 53047
Packaging	Tray
Part Status	Active
Connector Type	Header
Contact Type	Male Blade
Pitch - Mating	0.049" (1.25mm)
Number of Positions	12
Number of Rows	1
Row Spacing - Mating	-
Number of Positions Loaded	All
Style	Board to Cable/Wire
Shrouding	Shrouded - 4 Wall
Mounting Type	Through Hole
Termination	Solder
Fastening Type	Detent Lock
Contact Length - Mating	0.089" (2.25mm)
Contact Length - Post	0.091" (2.30mm)
Overall Contact Length	-
Insulation Height	0.165" (4.20mm)
Contact Shape	Rectangular
Contact Finish - Mating	Tin
Contact Finish Thickness - Mating	35.4µin (0.90µm)
Contact Finish - Post	Tin
Contact Material	Phosphor Bronze
Insulation Material	Polyamide (PA66), Nylon 6/6
Features	-
Operating Temperature	-
Ingress Protection	-
Material Flammability Rating	UL94 V-0
Insulation Color	Natural
Current Rating (Amps)	-
Voltage Rating	-
Mated Stacking Heights	-
Contact Finish Thickness - Post	-
Applications	Automotive, General Purpose, Industrial, Medical
Base Product Number	053047
