The ICM-42627, manufactured by InvenSense / TDK, is a SmartMotion™ sensor that ranks as a leading 6-axis MEMS MotionTracking device. This advanced sensor is equipped with a 3-axis gyroscope and a 3-axis accelerometer, designed to facilitate precision tracking for gesture-based handheld devices such as pointing mice. With sensitivity at 16384 LSB/g and 16-bit resolution, the ICM-42627 combines exceptional performance in a compact LGA-14 package.
One of its key features includes supporting I2C and SPI serial communication through a configurable host interface. The device also offers a 2KB FIFO and 2 programmable interrupts, along with ultra-low-power wake-on-motion support to optimize system power efficiency. Additional notable features of the ICM-42627 encompass user-selectable gyro full-scale range and accelerometer full-scale range, user-programmable digital filters, and an embedded temperature sensor. The device operates on a VDD range of 1.71V to 3.6V, and has a separate digital IO supply, VDDIO from 1.71V to 3.6V.
As a professional InvenSense distributor, Nantian Electronics has a large number of ICM-42627 in stock. We also provide ICM-42627 parameters, ICM-42627 Datasheet PDF and pin diagram instructions for download.
Applications
What interface types does the ICM-42627 support?
The ICM-42627 supports I2C and SPI serial communication interfaces.
What is the operating voltage range of the ICM-42627?
The ICM-42627 operates within a voltage range of 1.71V to 3.6V.
