Diodes Incorporated AM4961GHTR-G1

Manufacturer Part Number :	AM4961GHTR-G1
Manufacturer :	Diodes Incorporated
Description :	IC MOTOR DRIVER PWM 14TSSOP
Package :	14TSSOP
Datasheet :	AM4961GHTR-G1.PDF
EDA / CAD Models :	AM4961GHTR-G1 by SnapEDA
Base Product Number :	AM4961
Stock Condition :	In Stock 68264, New Original

Quantity:

RFQ Add to RFQ List

Delivery:

Payment:

Request for Quotation

*Contact Name:

*Company Name:

*Email:

Country :

* Quantity

Remark :

Please fill the form and we'll get back to you within 24 hours.

Quick RFQ

Diodes Incorporated AM4961GHTR-G1

In Stock: 68264 Qty:

RFQ Now Add to RFQ list

The AM4961GHTR-G1 by Diodes Incorporated is an advanced motor driver designed to optimize the performance and reliability of brushless DC motors. Key features include a built-in Hall bias circuit and PWM speed control circuit, which ensure precise and efficient motor operation. The device also includes a minimal speed setup circuit to maintain consistent performance, along with rotation speed indication (FG) and rotation or lock state indication (RD) for enhanced monitoring capabilities. These features make it ideal for applications requiring dependable motor control.

Diodes Incorporated AM4961GHTR-G1 electronic part

In addition to its operational features, the AM4961GHTR-G1 is equipped with a built-in thermal shutdown circuit and lock protection, safeguarding the motor against overheating and mechanical jams. The output current limit further enhances the product's safety and longevity by preventing excessive current draw. Nantian Electronics, a professional distributor for Diodes Incorporated, offers a significant stock of the AM4961GHTR-G1 and provides comprehensive resources such as datasheets and pin diagrams for download. Their team is ready to offer competitive pricing and support for orders and inquiries.

Diodes Incorporated AM4961GHTR-G1 original reel label

Type	Description
Category	Integrated Circuits (ICs) PMIC - Motor Drivers, Controllers
Manufacturer	Diodes Incorporated
Series	-
Packaging	Tape & Reel (TR)
Part Status	Obsolete
Motor Type - Stepper	-
Motor Type - AC, DC	Brushless DC (BLDC)
Function	Driver - Fully Integrated, Control and Power Stage
Output Configuration	Half Bridge (2)
Interface	PWM
Technology	Bipolar
Step Resolution	-
Applications	General Purpose
Current - Output	1A
Voltage - Supply	3.5V ~ 16V
Voltage - Load	3.5V ~ 16V
Operating Temperature	-30°C ~ 90°C (TA)
Mounting Type	Surface Mount
Package / Case	14-TSSOP (0.173", 4.40mm Width) + 2 Heat Tabs
Supplier Device Package	14-HTSSOP
Base Product Number	AM4961
