Avago Technologies (Broadcom) ACPL-C87AT-500E

Manufacturer Part Number :	ACPL-C87AT-500E
Manufacturer :	Avago Technologies (Broadcom)
Description :	Optical Isolated Amp, 100Khz, 5Kv, Sso-8; No. Of Channels:1 Channel;
Datasheet :	ACPL-C87AT-500E.PDF
EDA / CAD Models :	ACPL-C87AT-500E by SnapEDA
Base Product Number :	ACPL-C87
Stock Condition :	In Stock 9375, New Original

Quantity:

RFQ Add to RFQ List

Delivery:

Payment:

Request for Quotation

*Contact Name:

*Company Name:

*Email:

Country :

* Quantity

Remark :

Please fill the form and we'll get back to you within 24 hours.

Quick RFQ

Avago Technologies (Broadcom) ACPL-C87AT-500E

In Stock: 9375 Qty:

RFQ Now Add to RFQ list

The Broadcom® ACPL-C87AT/C87BT isolation sensors utilize superior optical coupling technology, with sigma-delta analog-to-digital converter, chopper stabilized amplifiers, and a fully differential circuit topology to provide unequaled isolation-mode noise rejection, low offset, high gain accuracy and stability.

ACPL-C87AT-500E in tape packaging

Avago Technologies (Broadcom) ACPL-C87AT-500E

As a professional Broadcom distributor, Nantian Electronics has a large number of ACPL-C87AT-500E in stock. We also provide ACPL-C87AT-500E parameters, ACPL-C87AT-500E Datasheet PDF and pin diagram instructions for download.

Features

Unity gain
±0.5% (ACPL-C87BT) and ±1% (ACPL-C87AT) gain tolerance @ 25°C
–0.3 mV Input offset voltage
0.05% non linearity
25 ppm/°C gain drift vs. temperature
100 kHz bandwidth
0 to 2V nominal input range
Qualified to AEC-Q100 Grade 1 test guidelines
Operating temperature: –40°C to +125°C
Shutdown feature (active high)
15 kV/μs common-mode rejection at VCM = 1 kV
Working voltage, VIORM = 1414 Vpeak
Compact, surface mount stretched SO8 package

Applications

Automotive BMS battery pack voltage sensing
Automotive DC/DC converter voltage sensing
Automotive motor inverter DC bus voltage sensing
Automotive AC/DC (charger) DC output voltage sensing
Isolation interface for temperature sensing
General-purpose voltage sensing and monitoring

Product Attribute	Attribute Value
Manufacturer:	Broadcom Limited
Product Category:	Optically Isolated Amplifiers
RoHS:	Details
Output Type:	Digital to Analog Converter - DAC
Number of Channels:	1 Channel
Isolation Voltage:	5000 Vrms
If - Forward Current:	230 mA
Bandwidth:	100 kHz
Vos - Input Offset Voltage:	9.9 mV
Supply Voltage - Max:	5.5 V
Supply Voltage - Min:	3 V
Package / Case:	SSO-8
Minimum Operating Temperature:	- 40 C
Maximum Operating Temperature:	+ 105 C
Mounting Style:	SMD/SMT
Qualification:	AEC-Q100
Packaging:	Reel
Packaging:	Cut Tape
Packaging:	MouseReel
Amplifier Type:	Isolation
Brand:	Broadcom / Avago
Gain V/V:	1 V/V
Height:	3.18 mm
Ib - Input Bias Current:	100 nA
Isolation Type:	Optic
Length:	5.85 mm
Operating Supply Current:	15 mA
Operating Supply Voltage:	3 V to 5.5 V
